How To Measure Lug Nut Pattern

Measure from the center of the first hole to the outside edge of the second hole.

How to measure lug nut pattern. These two steps together will give you your bolt hole pattern. The bolt pattern consists of lug holes three or more holes surrounding the large hub bore located at the center of the wheel. Finding the bolt circle diameter 1. The two most common lug patterns are 4 on 4 and 5 on 4 12 hubs.

If you dont have the template handy you measure from the center of any hole skip a hole in either direction and then measure to the outside edge of that hole. For a 4 lug wheel measure center to center of two holes directly across from each other. You can easily identify your thread size and pitch with a simple thread pitch gauge available at any hardware store or you can simply take one of your lug nuts to your local hardware store and spin it onto the bolts they have on hand. Measuring a 6 bolt wheel requires you to measure center to center of two holes directly across from each other.

If your wheel has an even. Be sure that you skip one bolt when measuring. Typically this will be 4 5 6 or 8. The easiest way to estimate the 5 lug bolt pattern is to measure from the back of a hole to the center of the second hole.

Choose any lug bolt and measure the distance between the back of one lug to the center of another that is directly across from it. Find the distance from the top of 1 lug nut to the center of another for wheels with odd numbered bolts. Next youll measure how many inches apart the bolt holes are. This video will show you how to properly measure a bolt pattern on a 5 lug wheel.

Measure the distance between 2 parallel lug nuts for wheels with an even number of bolts. If you need the 4 6 or 9 lug page look here how to measure 4 6 or 8 lug wheel bolt pattern if you want a more accurate approach check out the wheel bolt circle calculators. Measure from center of one lug stud that the lug nut bolts on to to the center of the lug directly across from it if you have four six or eight lug hubs. The lug holes are the points on the wheel that accept the lug nut or lug bolt to securely fasten the wheel to your vehicle.

You can measure the distance in either direction. Measure using the metric side of the ruler in millimeters. A bolt pattern refers to the pattern required to bolt a wheelrim on your vehicle. A 5 lug pattern is where things can get confusing.

That should get you your bolt pattern measurement.
